Precision Post-Etch Punch Systems
Industry-leading post-etch punch systems engineered for multilayer PCB fabrication. Micron-level repeatability, in-line inspection, and 40+ years of field-proven technology — now with dedicated North American sales and service.
Product Lines
Three distinct platforms to address every post-etch punching requirement — from cost-effective production to HDI-grade precision.
ECP-4000 / ECP-8000
Enhanced Capability Punch — Flagship Series
The highest-precision platform. HDI and mil-spec grade with in-line coaxial inspection, 4/8 camera vision, bronze bushing die set, and ±0.0003" repeatability.
ATP-7800
8-Camera High-Throughput Platform
Engineered for high-volume fabricators. 9+ panels per minute with backward compatibility for legacy Optiline systems. A clear upgrade path for existing users.
ATP-1000 / 3000E
4-Camera Automatic Post-Etch Punch
Fully automatic, cost-effective post-etch punching with 4-camera vision and 8+ panels/min throughput. Proven Multiline precision at an accessible price point.
Platform Comparison
Select the platform that best matches your production requirements, panel specifications, and integration needs.
| Specification | ECP-4000/8000 | ATP-7800 | ATP-1000/3000E |
|---|---|---|---|
| Punch Repeatability | ±0.0003" | ±0.0005" | ±0.001" |
| Tooling Accuracy | ±0.0005" | ±0.0008" | — |
| Vision Repeatability | ±0.00005" | ±0.00005" | — |
| Throughput | 7–8 panels/min | 9+ panels/min | 8+ panels/min |
| Camera System | 4 or 8 (4+4) | 8 (4 top + 4 bottom) | 4 (top) |
| Panel Size (max) | 24" × 30" | 24" × 30" | 24" × 28" |
| Extended Panel Size | Up to 25" × 49" | Up to 25" × 49" | Contact factory |
| Min Material Thickness | 0.001" (1 mil)* | — | 0.002" (2 mil) |
| Operating System | Windows 11 | Windows 11 | Windows® |
| MES / SECS-GEM | Optional | Optional | Contact factory |
| Coaxial Inspection | Yes (ECP-8000) | — | — |
| Legacy Optiline Compat. | — | Yes (2-cam mode) | — |
| Bronze Bushing Die Set | Available | — | — |
| Certifications | CE | CE | CE |
| Best For | HDI, mil-spec, precision | High throughput, legacy upgrades | Cost-effective production |
* ECP-RF configuration. ECP-8000 can achieve ±0.00015" repeatability for pin lamination applications.
Our Heritage
The original innovators of optical post-etch punching — now manufacturing the next generation.
Multiline Technology pioneered optical post-etch punching in 1983, establishing the industry standard for inner-layer registration in multilayer PCB fabrication. For decades, Multiline and Optiline systems were the benchmark equipment found in fabrication shops worldwide.
WKK represented Multiline across Asia for more than 30 years, building deep expertise in the technology and an extensive installed base. In December 2016, WKK acquired the global product rights to the entire Multiline Technology product line — including the ATP, OPE, and ECP series.
Today, WKK Machinery manufactures the next generation of Multiline systems from our advanced facility in Dongguan, China, incorporating modern Windows 11 platforms, SECS-GEM MES integration, and continuous precision improvements refined over four decades of engineering.
With the establishment of WKK America, we are bringing dedicated sales, service, and technical support to North American PCB fabricators for the first time.
Product Documentation
Download detailed specifications, data sheets, and product comparison guides.
Scan for Instant Access
Point your phone camera at this QR code to access our product documentation on your mobile device.
Links to multiline-tech.com/downloads
Service & Support
Dedicated North American support built on decades of Multiline equipment expertise.
Field Service & Preventive Maintenance
Our North American service infrastructure provides on-site installation, commissioning, preventive maintenance, and emergency repair support. We are building a regional service network with experienced technicians who understand Multiline equipment inside and out.
Parts & Consumables
Genuine Multiline replacement parts, punch and die components, and consumables available directly from WKK America. We are establishing domestic parts inventory to minimize lead times. Punch and die sharpening services are also available.
Technical Support & Training
Remote diagnostics, operator training, and ongoing technical assistance. With direct access to the engineering team that designs and manufactures every Multiline system, we offer the depth of expertise only the original manufacturer can provide.
Building a World-Class Service Organization
WKK America is actively investing in a comprehensive North American service and support infrastructure. We are finalizing partnerships with experienced service providers, establishing regional parts depots, and expanding our technical support team. Detailed service plans, warranty programs, and support packages will be announced in the coming months. Please contact us to discuss your specific support requirements — we are committed to ensuring every Multiline customer receives responsive, expert service.
Contact Us
Whether you're evaluating equipment, need technical support, or want to schedule a meeting — we're here to help.
WKK America
Headquarters
San Jose, California, USA
Legacy Multiline / Optiline Users
Running legacy equipment? We support the full product family and can help with parts, service, upgrades, and migration to our latest generation systems.
